The Story
Description
SATCO NUVO S19946 2-foot LED Linear T5 Ballast Compatible Lamp has over 50 percent more energy savings when compared to standard T5 systems. The 11 watt, 3500K lamp provides enhanced safety thanks to the integrated thermal fuse located at the pins. The all-glass tube construction not only delivers exceptional clarity, but also adds a touch of elegance to any space.
Features:- Watts: 11W, Incandescent Equivalent: 50W
- Volts: Ballast Dependent, Shape: T5
- Base: Miniature Bi Pin, Ansi Base: G5
- Finish: White, Lumens: 1350L
- Temperature: Neutral White, CCT (Kelvin): 3500K
- Warranty: 5 Year Limited
Specs
| General | |
| Watts | 11W |
| Incandescent Equivalent | 50W |
| Volts | Ballast Dependent |
| Shape | T5 |
| Base | Miniature Bi Pin |
| Ansi Base | G5 |
| Finish | White |
| CCT (Kelvin) | 3500K |
| Temperature | Neutral White |
| CRI | 80 |
| Lumens | 1350L |
| Beam Spread | 185 |
| Dimmable | Yes-Dimmable |
| Rated Life | 50000 |
| Electrical | |
| Operating Frequency | 50/60Hz |
| Power Factor | 0.9 |
| Operating Temperature | -20C (-4F) to 45C (113F) |
| Physical | |
| MOL | 22.5 |
| MOD | 0.63 |
| Housing Color | None |
| Weight (lb.) | 0.13 |
| Additional Information | |
| Rated For Enclosed Fixture | Yes |
| Installation Notes | Not for use in vapor tight fixtures. |
| Warranty | 5 Year Limited |
| Compliance | |
| Safety Listing | cULus - Certified;cULus - Listed |
| Location Rating | Damp |
| California Status | Lawful for sale |
| Title 20 / 24 Status | Lawful for sale |
| RoHS Compliant | Yes |
| FCC Compliant | Yes |
