Description

USHIO 3000312 Germicidal lamps are Low-Pressure Mercury-Arc lamps that emit radiation peaking at 253.7nm(UV-C).
This output at 253.7nm is highly effective to inactivate microorganisms such as bacteria,virus, yeast and mold.

Features:
- Low Mercury Dose to Meet Environmental Demands
- Specially Formulated Coating Achieves High Output Over Long Life Hour
- High Purity Lamp Construction to Stabilize UV Output and Minimizes Depreciation (Averages 20-25% Depreciation at End of Life)
- Flexible Design Capability for Custom Lamp Development
- EPA Approved: Ushio EPA # Est.96093-JPN-1

Applications:
- Drinking Water
- Wastewater
- Air Conditioning System
- Pharmaceutical Processing
- Food Processing Facility
- Packaging Materials
- Laboratory/Research
- Photo-chemistry
- Clean Room
- Other Sterilization and Disinfection Needs

Specs

BRAND	USHIO
Ordering Code	3000312
UPC	048777373637
Lamp Series	Germicidal
Prod.Id / Ansi Code	G36T5L
Lamp Description	G36T5L
Item Type	Low Pressure Uv
Base	Single
Voltage	115V
Wattage	39W
Amperage	0.425
Burn Position	Any
Bulb Shape	T5
Finish	Clear
Front Glass Cover	No
Rated Life (Hr)	9000
Length	33.31 in (846mm)
Diameter	0.61in (15.5mm)
Spectral Peak	253.7
Ozone Free	No
UV output (w)	13

Additional Info

Manual:

Ushio Germicidal Low Pressure Mercury Arc Specs

Cross Reference

4DA17 GRAINGER
3084 AQUAFINE
3084 NORTH-AMERICAN-LAMPS
23443 OSRAM
23443 SYLVANIA
29267-2 PHILIPS TUV36T5/SP
292672 PHILIPS
1563073 PHILIPS
3000312 USHIO
04613523443 SYLVANIA
048777373637 UPC
4008321058058 OSRAM
8711500640369 PHILIPS
871150064036999 PHILIPS
G/36INCH/T5/1P/40W
G/36INCH/T5/FA6/39W/LOW-OZONE/G36T5L1P
G36T5-SP-OF-115
G36T5L-39W/0.425AMP HIKARI
G36T5L-39W GENERAL-ELECTRIC
G36T5L-3000312 USHIO
G36T5L/1P ATLANTIC-ULTRAVIOLET
G36T5L/1P IDEAL
G36T5L/1P NORTH-AMERICAN-LAMPS
G36T5L/1P WEDECO
G36T5L/39W/0.425AMP
G36T5L/SP AQUAFINE
G36T5L/SP ATLANTIC-ULTRAVIOLET
G36T5L/SP IDEAL
G36T5L/SP NORTH-AMERICAN-LAMPS
G36T5L/SP WEDECO
G36T5L HIKARI
G36T5L USHIO
G36T5SP/OF
LCI1S IDEAL
LCI1S NORTH-AMERICAN-LAMPS
LCI1S WEDECO
LCI2S IDEAL
LCI2S NORTH-AMERICAN-LAMPS
LCI2S WEDECO
LCI4S IDEAL
LCI4S NORTH-AMERICAN-LAMPS
LCI4S WEDECO
LMG36T5L LUMIACTION
MP36A ATLANTIC-ULTRAVIOLET
MP36A NORTH-AMERICAN-LAMPS
PW8H NORTH-AMERICAN-LAMPS
PW8H PORT-STAR
PW20H NORTH-AMERICAN-LAMPS
PW20H PORT-STAR
PW30 NORTH-AMERICAN-LAMPS
PW30 PORT-STAR
PW60 NORTH-AMERICAN-LAMPS
PW60 PORT-STAR
PW100 NORTH-AMERICAN-LAMPS
PW100 PORT-STAR
SH-15 IDEAL
SH-15 NORTH-AMERICAN-LAMPS
SH-15 WEDECO
SH15 IDEAL
SH15 NORTH-AMERICAN-LAMPS
SH15 WEDECO
TUV-36-T-5-SP PHILIPS
TUV-36T5/SP PHILIPS
TUV/36T5/SP PHILIPS
TUV36T5/SP-GERMICIDAL-L
TUV36T5/SP-GERMICIDAL-L PHILIPS
TUV36T5/SP PHILIPS
TUV36T5SP PHILIPS
UV36T5L LUMIACTION
